MBF8005

Overview

The Atosa MBF8005 is a top-mount, two-door reach-in refrigerator for commercial food storage. Its two solid swing-style doors provide access to the cabinet, while the stainless steel interior and exterior offer a wipe-clean surface suited to a working kitchen. The product is also listed as MBF8005GR in several sources.

Published sources do not agree on some specifications. Capacity is listed as both 43.2 and 44.5 cubic feet, temperature ranges vary, and listed exterior dimensions differ slightly. Check the specification sheet for the exact model and configuration before making a fit or storage decision.

Key Features

• Top-mounted refrigeration: The unit has a top-mounted compressor. A source identifies it as a heavy-duty Embraco compressor and describes the refrigeration system as self-contained and air-cooled.
• Digital temperature control: A Dixell digital temperature controller is identified in the product information.
• Two solid doors: The swing-style doors are self-closing when left open below 90 degrees and stay open when opened beyond 90 degrees, according to the product description.
• Magnetic door gaskets: The flexible magnetic gaskets help seal the cabinet, according to the product information.
• Six shelves: Sources describe six shelves; the product description specifies epoxy-coated wire shelves, each with a stated load capacity of up to 155 lb.
• Casters and locks: The product description lists four pre-installed 4-inch swivel casters, with brakes on two, and stainless steel door locks.
• Stated warranty: A product listing states a 2-year parts and labour warranty and a 5-year compressor warranty. Confirm applicable terms for the unit and purchase.

Specifications

• Brand: Atosa
• Model: MBF8005; also listed as MBF8005GR
• Type: Commercial reach-in refrigerator
• Compressor position: Top mount
• Doors: 2 solid swing-style doors
• Interior capacity: Listed as 43.2 cu. ft. in one source and 44.5 cu. ft. in another; verify the applicable figure.
• Temperature range: Sources list 33°F–40°F, 33°F–38°F, and 35°F–38°F. Confirm the specification for the exact unit.
• Exterior dimensions: One listing gives 51.7 in. W × 31.7 in. D × 81.3 in. H; another gives 51.8 in. W × 31.8 in. D × 81.4 in. H. Verify before planning placement.
• Weight: 340 lb, as listed by one source.
• Shelves: 6 epoxy-coated wire shelves; listed shelf load capacity up to 155 lb each.
• Construction: Stainless steel interior and exterior.
• Compressor: 1/5 HP; a product description identifies an Embraco compressor.
• Electrical: 115V, 60 Hz, single phase; a separate listing specifies 3.2 amps.
• Wattage: 590 W, as listed by one source.
• Plug: NEMA 5-15P.
• Refrigerant: R290 hydrocarbon.
• Mobility: Four pre-installed 4-inch swivel casters; brakes on two casters.
• Certifications and listings stated in the sources: ETL, ETL-Sanitation, cETLus, NSF, and ENERGY STAR. Source listings vary; check the markings on the specific unit.
• Warranty stated in a product listing: 2 years parts and labour; 5 years compressor.

Applications

This two-door reach-in provides upright refrigerated storage for commercial kitchens and storerooms. The six-shelf interior can be used to organize ingredients and prepared items for kitchen workflows; arrange stored products with the cabinet’s usable space and airflow in mind. Its solid doors suit back-of-house storage where product visibility through glass is not required.
