MCF8707GR

Overview

The Atosa MCF8707GR is a bottom-mount, two-glass-door merchandiser cooler for commercial use. Its 44.8 cu. ft. capacity and eight shelves provide room to organize chilled products while keeping them visible through the double-pane glass doors. LED interior lighting illuminates the cabinet, making this model suitable for customer-facing beverage and packaged-food displays as well as staff-accessed refrigerated storage.

The cabinet has a stainless steel exterior and interior. Its two doors are self-closing and include an automatic stay-open feature, recessed handles and magnetic gaskets. The MCF8707GR also has standard door locks and pre-installed casters.

Key Features

• Two glass doors: Double-pane glass provides a view of the refrigerated contents.
• Commercial storage: The cabinet has 44.8 cu. ft. capacity and eight shelves, with four pre-installed shelves per section.
• Interior visibility: LED lighting illuminates the cabinet.
• Door functions: Self-closing doors have an automatic stay-open feature. Recessed handles and magnetic gaskets are standard.
• Door security: Door locks are standard on the MCF8707GR.
• Refrigeration system: A heavy-duty Embraco compressor uses R290 refrigerant.
• Temperature control: An electronic temperature controller manages cabinet temperature.
• Mobility: Pre-installed casters are included.
• Optional shelf: The spec sheet lists extra shelf part number W0402395 for this model; each extra shelf includes four shelf clips.

Specifications

• Manufacturer: Atosa
• Model: MCF8707GR
• Equipment type: Bottom-mount glass-door merchandiser cooler
• Doors: Two glass doors
• Capacity: 44.8 cu. ft.
• Shelves: Eight total; four per section
• Exterior dimensions: 54 2/5" W x 31 7/10" D x 83 1/10" H
• Electrical: 115V, 60 Hz, single phase
• Rated current: 3.2 A
• Input power: 370 W
• Compressor rating: 1/5 HP
• Plug: NEMA 5-15P; spec sheet also identifies NEMA 15A/125V
• Refrigerant: R290
• Temperature range: +33°F to +45°F in the manual’s model table
• Recommended preservation setting: 35°F to 38°F, per the manufacturer’s spec sheet
• Casters: 4"
• Net weight: 485 lb
• Gross weight: 540 lb

Installation & Requirements

The MCF8707GR is specified for a 115V, 60 Hz, single-phase power supply. The manual says the supply voltage should remain within ±6% of the unit’s rated voltage for proper operation. The spec sheet identifies a NEMA 5-15P plug.

According to the manual, a thermomagnetic circuit breaker is not supplied and must be installed between the mains power point and the refrigerator’s power cable. The manual specifies that the electrical connection work is to be carried out by professionally qualified persons. It also directs the installer to use a breaker suited to the unit’s rated output and to confirm operation by checking that the pilot light in the main switch comes on.

The manual calls for placement in the coolest, best-ventilated part of the room, away from heat sources and direct sunlight. It warns users to keep ventilation openings clear and not to damage the refrigerant circuit. R290 is identified in the manual’s safety warnings as a flammable refrigerant, so the stated precautions for flammable materials apply.

Operation

Use the electronic temperature controller to regulate the cabinet. The manufacturer recommends setting the refrigerator between 35°F and 38°F for food preservation. The model table in the manual lists a broader temperature range of +33°F to +45°F; the recommended setting is the manufacturer’s guidance for preservation, not a replacement for applicable food-safety requirements.

The doors close automatically and can remain open using the automatic stay-open feature. The manual describes a digital control unit that regulates operating parameters and cautions users not to change the microcomputer parameters privately, as changes may damage the compressor or affect other functions. The manual also states a maximum shelf load of 176 lb. Keep the unit’s ventilation openings unobstructed during use.

Cleaning & Maintenance

The manual recommends regular cleaning and specifies cleaning the refrigerator unit each month. Before any cleaning, disconnect the refrigerator’s power-supply cable from the mains. Clean the exterior with mild detergent and dry it with a soft cloth; the manual cautions against abrasive detergents. For initial cleaning, it also instructs users to clean the refrigerator with mild detergent and dry it with a soft cloth.

The manufacturer’s spec sheet separately advises cleaning the condenser frequently to give the unit more fresh air. It does not state a specific condenser-cleaning interval. Keep the ventilation openings clear, and avoid damaging the refrigerant circuit during cleaning or handling. The manual states that component parts should be replaced with like components and that servicing should be performed by factory-authorized service personnel.

Applications

The MCF8707GR suits commercial settings that need refrigerated storage and a visible product display in one cabinet. Examples include cafés, convenience stores, cafeterias, restaurants and other food-service operations displaying bottled drinks, cans and packaged chilled items. Its glass doors and interior lighting make contents easy to see, while its shelves allow products to be arranged by type or service area. Check the stated dimensions, electrical requirements and temperature information against the intended space and use before selecting the unit.
