MCF8709GR

Overview

The Atosa MCF8709GR is a bottom-mount, two-section glass-door merchandiser refrigerator for commercial foodservice and retail settings. Its sliding glass doors let staff and customers see the contents, while LED interior lighting helps make products visible. Atosa lists the capacity as 44.9 cu. ft. The product information identifies beer, soda and other beverages as suitable display items.

The cabinet has a stainless steel exterior and interior. Its refrigeration system uses a heavy-duty Embraco compressor and R290 refrigerant, with an electronic temperature controller. The sliding-door model does not include door locks, according to Atosa’s spec sheet.

Key Features

• Two sliding glass doors: Provide access to the cabinet and visibility of displayed products.
• LED interior lighting: Illuminates the contents for product display.
• Stainless steel construction: Stainless steel is specified for both the interior and exterior.
• Refrigeration components: Heavy-duty Embraco compressor, electronic temperature controller and R290 refrigerant.
• Self-closing and stay-open door feature: Product information describes doors that close when left slightly open and can stay open when opened farther for loading. The spec sheet also lists a magnetic door gasket and double-pane glass doors.
• Organized storage: The unit has eight pre-installed epoxy-coated wire shelves, four per section. Product information states that each shelf supports up to 155 lb.
• Mobility: Four pre-installed 2-inch casters are listed for the unit.
• Display header: Atosa’s spec sheet provides dimensions for the model’s lighted header panel: 52 3/12 × 9 1/16 × 1/8 inches overall, with a 51 9/16 × 8 7/16-inch visual area.

Specifications

• Brand: Atosa
• Model: MCF8709GR
• Equipment type: Bottom-mount, two-section glass-door merchandiser refrigerator
• Capacity: 44.9 cu. ft. Atosa’s spec sheet lists 44.9 cu. ft.; the manual’s model table lists 44.85 cu. ft.
• Doors: Two sliding glass doors
• Shelves: Eight pre-installed shelves, four per section; epoxy-coated wire shelves are identified in product information
• Exterior and interior: Stainless steel
• Glass: Double-pane glass doors
• Lighting: Interior LED lights
• Temperature information: Atosa’s spec sheet recommends setting the refrigerator between 35°F and 38°F. The product overview lists 33°F to 38°F, while the manual’s technical table lists a range of 33°F to 45°F for the MCF8709GR.
• Compressor: Heavy-duty Embraco
• Refrigerant: R290; the manual’s MCF8709GR table lists a charge of 5.3 oz.
• Horsepower: 1/4 HP
• Electrical: 115V, 60Hz, 1 phase
• Rated current: 4.2A
• Input power: 470W, as listed in the manual’s model table
• Plug: NEMA 5-15P
• Dimensions: Atosa’s spec sheet lists 54 2/5 × 29 7/10 × 81 1/5 inches. Other product specifications express these dimensions as 54.4 × 29.7 × 81.2 inches.
• Weight: 456 lb net and 511 lb gross, according to Atosa’s spec sheet
• Casters: Four pre-installed 2-inch casters
• Door lock: Not available on the MCF8709GR sliding-glass-door model
• Safety and sanitation standards listed: UL 471; CSA C22.2 No. 120; NSF/ANSI 7

Installation & Requirements

The supplied installation instructions specify a 115V, 60Hz, single-phase power supply for the MCF8709GR. They state that the supply voltage should remain within ±6% of the unit’s rated voltage. The refrigerator is supplied with a power cord. A thermomagnetic circuit breaker, which is not supplied, must be installed between the mains power point and the refrigerator’s power cable. The manual says this electrical connection must be carried out by professionally qualified personnel.

Before connecting the unit, the manual directs the installer to remove the packaging straps, cardboard and PET protective film. It says to clean the refrigerator with mild detergent and dry it with a soft cloth before use. Position the unit in the coolest, best-ventilated part of the room and do not install it near heat sources or direct sunlight. The provided sources do not specify a clearance measurement.

The manual warns that R290 is a flammable refrigerant and cautions against damaging the refrigerant circuit. It also says to keep ventilation openings clear and not to use mechanical devices or other means to accelerate defrosting unless recommended by the manufacturer. Service involving components should use like components and be performed by factory-authorized service personnel, as stated in the manual.

Operation

The refrigerator uses an electronic temperature controller to regulate its operating parameters. Atosa recommends a refrigerator setting between 35°F and 38°F for food preservation. Product information separately lists a 33°F to 38°F operating range, and the manual’s technical table gives a 33°F to 45°F range for this model. These figures are presented differently in the supplied sources; consult the unit’s documentation and controller information for operating settings.

The manual cautions users not to change the microcomputer parameters privately, explaining that the factory sets them to help avoid damage to the compressor unit or other functions. It identifies the digital control unit as the control for the refrigerator’s parameters and refers operators to the separate digital-control-unit attachment for those parameters. The instructions also describe a keyboard lock: holding the specified keys for more than three seconds displays “OF,” and holding the unlock keys together for more than three seconds displays “on.”

For loading, the product information describes sliding doors that can stay open when opened far enough and close automatically when left slightly open. The cabinet’s interior lighting and glass doors support viewing products without opening the cabinet.

Cleaning & Maintenance

The manual recommends regular cleaning of the refrigerator and specifically advises disconnecting its power-supply cable from the mains before any cleaning operation. For the refrigerator’s surfaces, use mild detergent and dry with a soft cloth. The manual warns against abrasive detergents.

The product information describes flexible magnetic door gaskets that help maintain internal temperatures and keep dust and debris out. Atosa’s spec-sheet guidance says to clean the condenser frequently to give the unit more fresh air. The sources do not provide a specific cleaning interval for the condenser.

Applications

The MCF8709GR is intended for commercial use. Its glass-door merchandising format is suited to displaying and cooling beverages such as beer and soda, as well as other products appropriate for refrigerated display. The two sections, eight shelves and 44.9 cu. ft. capacity provide space for arranging products for staff access or customer viewing in settings such as restaurants, cafés, delis and convenience stores.
