MCF8721ES

Overview

The Atosa MCF8721ES is a two-section, two-door commercial freezer merchandiser for frozen products that need to be visible to customers or staff. Its 43.8 cu. ft. capacity and eight adjustable shelves provide space to organize products by type or category. The black steel exterior gives the cabinet a retail-style appearance, while the stainless steel interior is intended for commercial use.

Double-pane glass doors provide a view of the contents without opening the cabinet. Each door is self-closing and has an automatic stay-open feature, a recessed handle, a lock and a magnetic gasket. The unit includes a lighted header panel and standard LED interior lighting to make displayed products easier to see.

Key Features

• Freezer temperature range: The electronic temperature controller maintains the cabinet between -8°F and 0°F. The manufacturer recommends setting the freezer within this range for food preservation.
• Merchandising visibility: Double-pane glass doors, LED interior lighting and a lighted header panel support customer-facing product display.
• Organized storage: Eight standard shelves, four per section, provide adjustable storage for different frozen merchandise.
• Door features: Self-closing doors include an automatic stay-open feature, recessed handles, standard locks and magnetic door gaskets.
• Bottom-mounted refrigeration: The self-contained system uses a 3/4 HP compressor and R290 refrigerant.
• Cabinet construction: The exterior is black steel and the interior is stainless steel.
• Mobility: Casters are pre-installed.

Specifications

• Brand: Atosa
• Model: MCF8721ES
• Equipment type: Two-section glass door freezer merchandiser
• Capacity: 43.8 cu. ft.
• Temperature range: -8°F to 0°F
• Voltage, frequency and phase: 115V / 60Hz / 1 phase
• Rated current: 8.6 A
• Input power: 935 W
• Compressor: 3/4 HP
• Refrigerant: R290; 5.3 oz. listed in the supplied manual’s technical table
• Refrigeration system: Self-contained, bottom mount
• Doors: Two double-pane glass doors; self-closing with automatic stay-open feature, locks, recessed handles and magnetic gaskets
• Shelves: Eight standard shelves, four per section; adjustable
• Lighting: LED interior lighting and lighted header panel
• Exterior: Black steel
• Interior: Stainless steel
• Dimensions: 54 2/5 in. W × 31 1/2 in. D × 81 1/5 in. H
• Plug: NEMA 5-15P

Installation & Requirements

The supplied Atosa manual specifies a 115V / 60Hz / 1-phase supply for the MCF8721ES and says the supply voltage should remain within ±6% of the unit’s rated voltage for proper operation. The product specification lists a NEMA 5-15P plug. The manual says a thermomagnetic circuit breaker, not supplied with the unit, must be installed between the mains supply point and the freezer’s power-supply cable. It states that this electrical connection must be carried out by professionally qualified persons.

Position the freezer in a cool, well-ventilated part of the room, away from heat sources and direct sunlight. Keep the ventilation openings in the appliance enclosure or built-in structure unobstructed. The supplied sources do not specify a numerical clearance requirement.

R290 is a flammable refrigerant. The manual warns against damaging the refrigerant circuit and identifies a risk of fire or explosion from flammable refrigerant. It also warns not to use mechanical devices or other means to accelerate defrosting unless recommended by the manufacturer, and not to use electrical appliances inside food-storage compartments unless they are of a type recommended by the manufacturer. The manual advises consulting a service agent or similarly qualified person for disposal.

Operation

The electronic controller regulates the freezer’s operating parameters. Use the controller to manage the temperature within the stated -8°F to 0°F range; the manufacturer recommends setting the freezer within this range for food preservation. The supplied manual notes that a changed set value is stored even if the setting procedure is exited by waiting for the time-out.

The controller keyboard can be locked by holding the indicated keys for more than three seconds; the display shows “OF” when locked. To unlock it, hold the indicated keys together for more than three seconds until “on” appears. The manual also refers to controller alarm signalling and a separate digital-control-unit parameter manual. It cautions users not to change microcomputer parameters, as the factory settings are intended to protect the compressor and other functions.

Cleaning & Maintenance

Before cleaning, disconnect the freezer’s power-supply cable from the mains. The manual recommends regular cleaning of the refrigerator unit each month. Clean the surface with mild detergent and dry it with a soft cloth. The manufacturer’s specification sheet also recommends cleaning the condenser frequently to help it receive fresh air; it does not prescribe a specific interval.

Keep the freezer’s ventilation openings clear. The manual warns against unauthorized modification and the use of non-original spare parts, and says servicing should be performed by factory-authorized personnel. For any cleaning or service work, disconnect the power first as directed by the manual.

Applications

The MCF8721ES suits customer-facing frozen product display in settings such as convenience stores, food retailers and commercial kitchens with a merchandising area. Its glass doors and illuminated header support visible product presentation, while the lockable doors and adjustable shelves also suit organized frozen storage. Confirm that the available electrical supply matches the unit’s stated requirements before selecting a location.
