MCF8725GR

Overview

The Atosa MCF8725GR is a single-door, glass-door refrigerator merchandiser for commercial use. Its black steel exterior and stainless steel interior provide a contrasting finish for customer-facing foodservice areas. The double-pane glass door, lighted header panel and standard LED interior lighting make refrigerated products visible inside the cabinet. The listed capacity is 11.1 cu. ft.

This model uses a self-contained, bottom-mount refrigeration system with R290 refrigerant. Atosa lists the maintained temperature as 35°F–38°F, while the model table in the installation and operation manual gives a temperature range of +33°F to +45°F. The specification sheet recommends setting the refrigerator between 35°F and 38°F for food preservation.

Key Features

• Glass merchandising door: The double-pane glass door provides a view into the refrigerated cabinet.
• Interior and header lighting: LED interior lighting is standard, and the lighted header panel adds a visible display area above the door.
• Electronic temperature control: The electronic controller regulates the refrigerator’s operating parameters.
• Four included shelves: Four shelves are standard; additional shelves are listed as an optional accessory.
• Door features: The door is self-closing and has an automatic stay-open feature. It also includes a recessed handle, standard lock and magnetic gasket.
• Refrigeration system: The self-contained system is bottom-mounted and uses R290 refrigerant.
• Ready-fitted components: Casters and shelves are pre-installed.

Specifications

• Manufacturer: Atosa
• Model: MCF8725GR
• Equipment type: One-door glass merchandiser refrigerator
• Capacity: 11.1 cu. ft.
• Exterior: Black steel
• Interior: Stainless steel
• Doors: One double-pane glass door
• Shelves: Four standard shelves
• Exterior dimensions: 24 1/5 in. W × 24 in. D × 76 1/5 in. H
• Net weight: 227 lb
• Gross weight: 251 lb
• Electrical supply: 115 V, 60 Hz, single phase
• Rated current: 2.1 A
• Input power: 250 W, according to the model table in the supplied manual
• Compressor rating: 1/7 HP
• Temperature range in the manual’s model table: +33°F to +45°F
• Recommended preservation setting: 35°F–38°F
• Refrigerant: R290; refrigerant amount listed in the manual: 3.9 oz
• Connection: NEMA 5-15P; the specification sheet also lists NEMA 15A/125V
• Casters: Pre-installed
• Warranty stated on the specification sheet: Three years parts and labour; five years compressor parts
• Optional accessory: Extra shelves, supplied with four shelf clips per shelf

Installation & Requirements

The supplied installation and operation manual states that the appliance is for commercial use only. It lists the MCF8725GR power supply as 115 V, 60 Hz, single phase, and says the supply voltage should remain within ±6% of the unit’s rated voltage. The product specifications identify a NEMA 5-15P plug.

The manual says electrical connection work must be carried out by professionally qualified people. It calls for a suitably rated thermal-magnetic circuit breaker between the mains power point and the refrigerator’s power-supply cable; the breaker is not supplied. The manual describes connecting the refrigerator to the breaker outlet and checking that the pilot light in the main switch illuminates. Follow the unit’s supplied instructions and applicable electrical requirements for the installation.

For placement, the manual calls for a cool, well-ventilated part of the room and says not to install the refrigerator near heat sources or direct sunlight. It also warns that ventilation openings in the appliance enclosure or built-in structure must remain unobstructed. Keep the refrigeration circuit undamaged. Because the unit uses flammable R290 refrigerant, the manual identifies a fire and explosion risk and cautions against storing explosive substances, such as aerosol cans with a flammable propellant, inside the appliance.

Operation

The electronic control unit regulates the refrigerator’s operating parameters. The manual directs operators to the separate digital-control-unit instructions for control parameters and says not to change the microcomputer parameters privately, as changes may damage the compressor or other functions. For food preservation, Atosa recommends setting the refrigerator between 35°F and 38°F. The operating range listed for this model in the manual is +33°F to +45°F.

The door closes automatically and includes an automatic stay-open feature. A door lock is standard. The manual includes a keyboard lock function on the digital controller: its described display indication is “OF” when locked and “on” when unlocked. The extracted manual text does not clearly preserve the button sequence, so refer to the complete controller instructions for the correct key operation.

Cleaning & Maintenance

The manual recommends cleaning the refrigerator regularly, with monthly cleaning specifically stated. Before any cleaning operation, disconnect the refrigerator’s power-supply cable from the mains. For the refrigerator surface, the manual says to clean with mild detergent and dry with a soft cloth. It also warns not to use mechanical devices or other means to accelerate defrosting unless recommended by the manufacturer.

The Atosa specification sheet separately advises cleaning the condenser frequently and notes that the unit needs room to breathe. Keep the ventilation openings clear, as required by the manual. The manual warns that servicing and component replacement must follow its instructions, including use of like components; it also lists improper installation, misuse, power-supply defects, inadequate maintenance, unauthorised modification and non-original spare parts among circumstances for which the manufacturer cannot be held liable.

Applications

The MCF8725GR is a refrigerated merchandiser for commercial settings that need chilled products visible through a glass door. Its 11.1 cu. ft. capacity, four standard shelves and interior lighting support organized display and storage of refrigerated products. The source materials identify it as a commercial refrigerator and provide a recommended preservation setting of 35°F–38°F.
