MGF8405GR

Overview

The Atosa MGF8405GR is a 27-inch, one-door commercial undercounter freezer. Its 7.2 cu. ft. capacity provides frozen storage below the work surface, making it a practical option for kitchens that need ingredients close to a prep or service area. The stainless steel exterior and interior, together with a reinforced stainless steel top, give the unit a cleanable work surface and cabinet construction.

The freezer uses R290 refrigerant and an electronic temperature controller. Atosa lists a temperature range of -8°F to 0°F. The model comes with one pre-installed shelf and pre-installed casters.

Key Features

• Stainless steel construction: Stainless steel exterior and interior with a reinforced stainless steel top.
• Temperature control: Electronic temperature controller; the stated operating range is -8°F to 0°F.
• Door: Recessed handle and self-closing action with a stay-open feature. A magnetic door gasket is standard for a positive door seal.
• Storage: One pre-installed shelf per section. Extra shelves are listed as optional accessories and include four shelf clips per shelf.
• Mobility: Pre-installed casters.
• Refrigerant: Environmentally friendly R290 refrigerant.

Specifications

• Manufacturer: Atosa
• Model: MGF8405GR
• Equipment type: Undercounter freezer
• Nominal width: 27 inches
• Capacity: 7.2 cu. ft.
• Doors: 1
• Shelves: 1 pre-installed shelf
• Exterior dimensions: 27 1/2 × 30 × 34 1/2 inches
• Electrical: 115 V, 60 Hz, 1 phase
• Electrical plug information shown on the specification sheet: NEMA 5-15P; NEMA 15A/125V
• Refrigerant: R290
• Compressor horsepower: 1/5 HP
• Casters: Pre-installed; the specification sheet lists 2-inch casters.
• Net weight: 146 lb
• Gross weight: 179 lb

Installation & Requirements

The specification sheet lists an electrical requirement of 115 V, 60 Hz, single phase, and identifies a NEMA 5-15P plug and NEMA 15A/125V. Atosa's freezer guidance says to leave the unit room to breathe; the provided information does not give a specific clearance measurement. The unit has pre-installed casters. No gas connection is specified for this freezer.

Operation

The MGF8405GR uses an electronic temperature controller and is listed as maintaining temperatures between -8°F and 0°F. For best food-preservation results, Atosa recommends setting the freezer between -8°F and 0°F. The door is self-closing and includes a stay-open feature; its magnetic gasket is intended to provide a positive door seal.

Cleaning & Maintenance

Atosa advises cleaning the condenser frequently to give the unit more fresh air. The source does not specify a cleaning interval or provide a step-by-step condenser-cleaning procedure. The stainless steel interior and exterior are identified as construction features; follow the product documentation for any cleaning method or chemical guidance.

Applications

The MGF8405GR suits commercial kitchens that need compact, nearby frozen storage, such as a restaurant prep area or service station. Its undercounter format keeps frozen ingredients within reach while preserving the work surface above the cabinet. The single-door layout and one included shelf provide a straightforward storage arrangement; optional extra shelves are available for the model.
