MGF8452GR

Overview

The Atosa MGF8452GR is a 60-inch refrigerated chef base with an extended top and two drawers. It places chilled ingredient storage beneath a heavy-duty work surface that can support countertop equipment, keeping refrigerated items close to the cooking station. The published capacity is 8.4 cu. ft.; the unit includes six 12 × 20-inch stainless steel pans.

Its stainless steel interior and exterior, electronic temperature controller and self-contained refrigeration system make it suitable for commercial kitchen use. The specification sheet identifies R290 refrigerant, pre-installed casters and a one-piece reinforced stainless steel top. Atosa’s manual states that the appliance is intended for commercial use only.

Key Features

• Extended equipment-supporting top: A one-piece, heavy-duty reinforced stainless steel top supports countertop equipment and provides a work surface.
• Two refrigerated drawers: The drawers have heavy-duty stainless steel slides and rollers, magnetic gaskets and recessed handles. The specification sheet states that the drawers hold and include 6-inch-deep stainless steel pans.
• Included pans: Six 12 × 20-inch stainless steel pans are listed for this model.
• Temperature control: An electronic temperature controller manages the refrigerated cabinet. The product specification sheet lists a holding range of 35°F to 38°F.
• Refrigeration system: A heavy-duty compressor uses R290 refrigerant. The product information identifies the system as self-contained.
• Stainless steel construction: The exterior and interior are stainless steel.
• Mobility and protection: Pre-installed 5-inch casters, corner guards and pull-out handles are included.

Specifications

• Manufacturer: Atosa
• Model: MGF8452GR
• Equipment type: Refrigerated chef base with extended top
• Capacity: 8.4 cu. ft.
• Drawers: 2
• Pans per unit: 6 × 12 × 20-inch stainless steel pans; drawers are specified to hold 6-inch-deep pans
• Exterior dimensions: 60 1/2 × 33 × 26 3/5 inches (W × D × H)
• Net weight: 234 lb
• Gross weight: 282 lb
• Electrical: 115 V, 60 Hz, single phase; 2.3 A; 1/7 HP
• Plug and receptacle information: NEMA 5-15P; NEMA 15A/125V
• Temperature: The Atosa specification sheet lists 35°F to 38°F. The manual’s technical table lists +1°C to +8°C for MGF8452GR.
• Refrigerant: R290
• Casters: 5 inches; pre-installed
• Construction: Stainless steel interior and exterior; one-piece heavy-duty reinforced stainless steel top
• Warranty stated in the specification sheet: 2 years parts and labour; 5 years compressor parts

Installation & Requirements

The manual specifies a 115 V outlet for the appliance. Before connection, it instructs the installer to check that the electrical supply matches the requirements on the factory label and is provided with full safety protection or an automatic circuit. The manual also identifies a grounding terminal. The specification sheet lists a NEMA 5-15P plug and NEMA 15A/125V.

Keep air circulation around the condensing unit unobstructed. The manual cautions against installation in an explosive atmosphere and says the appliance should be protected from rain, direct sunlight and draughts, and kept away from direct heat sources such as radiators and direct lighting. It does not provide a numeric clearance requirement. If the unit has been positioned horizontally, the manual says to wait two hours before activating it.

The manual states that defrost water is dispersed automatically on models with an integral condensing unit. The MGF8452GR product information identifies its refrigeration system as self-contained.

Operation

Use the electronic temperature controller to check and adjust the setpoint. In the manual’s XR06CX controller instructions, pressing and releasing the SET key displays the setpoint. To change it, press SET for more than two seconds; when the setpoint appears and the temperature indicator flashes, use the arrow keys to adjust the value. Press SET again to save, or wait 10 seconds for the setting to be stored.

The same controller instructions describe starting a manual defrost by holding the DEF key for more than two seconds. The manual says the keyboard can be locked by holding the indicated key combination for more than three seconds and unlocked by holding the corresponding combination until the display shows “on”; the key symbols are not legible in the supplied text. For food preservation, Atosa’s specification sheet recommends setting the refrigerator between 35°F and 38°F. The manual’s MGF8452GR technical table lists a temperature range of +1°C to +8°C.

Cleaning & Maintenance

Before use, the manual calls for cleaning the cabinet’s walls and internal parts with an antibacterial detergent. For plastic parts, it specifies a damp cloth, followed by drying with a soft, clean cloth. It advises using little or no water and avoiding harsh or abrasive solvents and detergents.

The manual warns that parts such as the evaporator and condenser may have sharp edges. Use protective gloves when cleaning near them, and do not approach these parts with bare hands. Atosa’s specification sheet also advises cleaning the condenser frequently so the unit can receive fresh air; it does not state a fixed cleaning interval.

The manual says the equipment’s refrigerant and insulation blowing gas require special disposal procedures. It directs users to consult a service agent or similarly qualified person for disposal.

Applications

Place the MGF8452GR beneath compatible countertop cooking equipment when a kitchen needs refrigerated ingredients within reach of the cooking line. The reinforced top supports countertop equipment, while the two drawers and included pans keep prepared ingredients organised and accessible. Its extended top can also serve as a nearby work surface for tasks such as staging ingredients or plating.
