MKC23GR

Overview

The Atosa MKC23GR is a 23-inch direct-draw keg cooler for commercial beverage service. A dual-tap tower dispenses draft beer directly from the refrigerated cabinet, while the stainless steel interior and exterior provide a practical surface for a busy bar or restaurant. The product listing describes one double-tap tower, and the manual identifies the model as MKC23GR.

The user manual reports a cabinet volume of 7.09 cu. ft.; a Canadian retailer rounds this to 7.1 cu. ft. The manual and retailer listings do not agree on every published specification. The differences are called out below rather than presented as a single confirmed figure.

Key Features

• Direct-draw dispensing: A dual-tap tower provides two taps for serving draft beer from the cooler.
• Stainless steel construction: A Canadian product listing specifies stainless steel for both the exterior and interior.
• Digital temperature control: The product listing identifies a digital electronic controller.
• Refrigeration components: A product listing specifies a heavy-duty Embraco compressor and R290 refrigerant. Another listing notes that the compressor assembly slides out for maintenance access.
• Cabinet components: The parts manual identifies a countertop assembly, sink, faucet, door, lock and key, evaporator and condenser components, and a digital controller. These are parts-manual component names; the source does not provide operating instructions for them.
• Casters: A product listing describes preinstalled casters. The parts manual lists 3.5-inch-stem casters with and without brakes, two of each.

Specifications

• Manufacturer: Atosa
• Model: MKC23GR
• Equipment type: 23-inch direct-draw keg cooler / beer dispenser
• Tap configuration: One dual-tap tower, as described in the Canadian product listing
• Exterior and interior: Stainless steel, per the Canadian product listing
• Capacity: 7.09 cu. ft. in the user manual; 7.1 cu. ft. in the Canadian product listing
• Temperature: The user manual lists +32°F to +50°F. A Canadian product listing states 33°F to 40°F. These published ranges differ.
• Voltage: 115 V
• Frequency: 60 Hz
• Phase: 1 phase, per the Canadian product listing
• Current: 2.3 A
• Input power: 260 W in the user manual; 265 W in the Canadian product listing
• Compressor: 1/7 HP, per the merged product specifications; a Canadian product listing identifies a heavy-duty Embraco compressor
• Refrigerant: R290; the user manual lists a charge amount of 2.8 oz.
• Electrical connection: NEMA 5-15P, per the Canadian product listing
• Dimensions: The user manual lists 23 × 29.5 × 39.3 inches. The Canadian product listing gives a width of 23 inches, depth of 31.1 inches and height of 39.25 inches. The listed depths differ.
• Weight: 132 lb, per the Canadian product listing
• Certifications reported by a Canadian product listing: ETLC Certified and NSF Certified

Installation & Requirements

The user manual’s model table specifies a 115 V power source and 60 Hz frequency for the MKC23GR. A Canadian product listing additionally reports single-phase power, 2.3 A current and a NEMA 5-15P connection. Confirm the unit’s rating information and site electrical compatibility before connecting it. The available manual extract does not provide installation steps, clearance dimensions, ventilation requirements or other site-preparation instructions, so none are specified here.

Operation

The MKC23GR serves draft beer through its dual-tap tower, with the keg held in the refrigerated cabinet. A digital electronic controller is identified in the product listing. Published temperature information is inconsistent: the user manual gives +32°F to +50°F, while the Canadian listing states 33°F to 40°F. Consult the documentation supplied with the unit for the applicable operating range and controller instructions; the available manual extract does not include control settings or operating procedures.

Cleaning & Maintenance

The stainless steel interior and exterior are specified in the Canadian product listing, but the supplied manual extract does not include cleaning methods, approved cleaning products or a maintenance schedule. A product listing notes that the compressor assembly slides out for maintenance access. The parts manual identifies refrigeration and dispensing components, including the compressor, condenser, evaporator, fans, drain pan, faucet and tubing; it does not provide service procedures for these parts.

Applications

The MKC23GR is suited to commercial bar and restaurant beverage service where a compact direct-draw cooler and two draft taps fit the operation. Its 23-inch width and 7.09 cu. ft. manual-listed capacity make the stated cabinet dimensions and keg fit important items to verify for the intended setup. The available sources do not specify keg sizes or the number of kegs the cabinet holds.
