MSF8308GR

Overview

The Atosa MSF8308GR is a 72-inch refrigerated mega-top sandwich prep table for commercial kitchens that prepare sandwiches, salads and other made-to-order items. It brings a refrigerated ingredient rail, a 9-1/4-inch cutting board and cabinet storage together in one three-door unit. The mega-top layout provides 30 positions for 1/6-size pans, while the cabinet offers 21.1 cu. ft. of capacity.

Atosa specifies a temperature range of 35°F–38°F and recommends setting the refrigerator between 35°F and 38°F for the best results in food preservation. The unit has a rear-mounted compressor using R290 refrigerant. Its stainless steel exterior and interior, electronic temperature controller, removable stainless steel pan liner and pre-installed casters are among the standard features listed by the manufacturer.

Key Features

• Mega-top ingredient rail: The top accommodates 30 1/6-size pan positions. The manufacturer lists pre-installed 6-inch-deep poly pans and locking divider bars.
• Refrigerated cabinet storage: Three doors provide access to 21.1 cu. ft. of storage. One shelf is pre-installed per section.
• Prep surface: A 9-1/4-inch cutting board provides a work surface alongside the ingredient pans.
• Temperature control: An electronic temperature controller supports the specified operating range of 35°F–38°F.
• Air distribution: Atosa describes a concentrated airflow design intended to distribute airflow evenly around the pans, along with an unmatched cabinet airflow design.
• Door details: The doors have recessed handles, self-closing action with a stay-open feature, and magnetic gaskets for a positive seal.
• Mobility and construction: The unit has pre-installed casters and stainless steel exterior and interior surfaces.
• Optional accessories: Atosa lists a double overshelf for 72-inch models and night covers as optional accessories. A 12-inch cross bar, part number 82021902, is also listed as an optional accessory.

Specifications

• Brand: Atosa
• Model: MSF8308GR
• Equipment type: Refrigerated mega-top sandwich prep table
• Exterior dimensions: 72-7/10 × 36-3/4 × 46-5/8 inches
• Storage capacity: 21.1 cu. ft.
• Pan capacity: 30 positions for 1/6-size pans
• Pans: Pre-installed 6-inch-deep poly pans
• Doors: 3
• Shelves: 3 total; one pre-installed shelf per section
• Cutting board: 9-1/4 inches
• Temperature range: 35°F–38°F
• Electrical: 115 V, 60 Hz, single phase
• Amperage: 2.8 A
• Plug: NEMA 5-15P
• Compressor: 1/5 HP, rear-mounted
• Refrigerant: R290
• Net weight: 331 lb
• Gross weight: 401 lb
• Construction: Stainless steel exterior and interior
• Certifications and standards: Conforms to UL Standard 471; certified to CSA Standard C22.2 No. 120
• Warranty stated on the manufacturer spec sheet: 3-year parts and labour; 5-year compressor parts

Installation & Requirements

The listed electrical supply is 115 V, 60 Hz, single phase, at 2.8 A. The unit is specified with a NEMA 5-15P plug. The manufacturer’s spec sheet notes that the unit needs room to breathe. The available product information does not give a specific clearance dimension.

The compressor is rear-mounted and uses R290 refrigerant. The manufacturer does not provide a gas connection requirement for this refrigerated unit in the supplied product information.

Operation

The electronic temperature controller is used to control the refrigerator. Atosa specifies that the unit maintains temperatures between 35°F and 38°F and recommends setting the refrigerator within that range for the best results in food preservation. The ingredient rail’s 1/6-size pan positions support organizing sandwich and salad ingredients, while the cutting board provides an adjacent prep surface. The cabinet is accessed through three self-closing doors; each door has a stay-open feature for loading or retrieving items.

The manufacturer lists locking divider bars and a removable stainless steel pan liner as standard features. The liner can be removed for cleaning, and the divider bars secure the pan layout. Pre-installed shelves provide one shelf in each cabinet section.

Cleaning & Maintenance

Atosa advises cleaning the condenser frequently so the unit can receive more fresh air. The manufacturer also notes that the refrigerator needs room to breathe. No cleaning interval, cleaning solution, or detailed cleaning procedure is provided in the available model information. The removable stainless steel pan liner is identified as a standard feature.

Applications

The MSF8308GR is suited to food-service prep lines that need chilled ingredients close to the work surface. Its 30 pan positions can be arranged for sandwich fillings, salad toppings, sliced meats, cheeses, vegetables, sauces and other prepped ingredients. The broad cutting board and mega-top format support assembly work, while the three-door cabinet stores additional ingredients below the prep area. It can serve sandwich shops, delis, cafés and restaurant kitchens where staff assemble made-to-order dishes during service.
