MSF8311

Overview

The Atosa MSF8311 is a 48-inch stainless steel two-drawer sandwich prep table for commercial kitchen use. It has 12 cubic feet of capacity and two sections of self-contained refrigeration. The refrigeration system is rear mounted, while the two drawers provide access to refrigerated storage during prep and service.

The provided Atosa installation and operation manual lists MSF8311 among its salad prep table models. Its instructions cover positioning, electrical connection, food storage, defrosting, cleaning and basic troubleshooting for the equipment family. Use the product identification label on the unit for its specific electrical requirements.

Key Features

• Two-drawer prep table: A 48-inch stainless steel work surface with two refrigerated sections.
• 12-cubic-foot capacity: Refrigerated storage capacity for ingredients and other food items used during service.
• Self-contained refrigeration: Refrigeration is built into the unit, with the system mounted at the rear.
• Digital temperature control: A digital controller uses a microprocessor, and the manual refers to checking the digital display for the operating temperature.
• Defrost and lighting: The listed features include air defrost and automatic lighting. The manual describes an automatic defrost timer.
• Drawer and door function: The product listing identifies a self-closing and stay-open door feature. The manual advises opening one drawer at a time and avoiding frequent or prolonged openings.
• Galvanized steel backing: The product listing specifies galvanized steel for the backing.

Specifications

• Brand: Atosa
• Model: MSF8311
• Product type: Two-drawer sandwich prep table
• Width: 48 inches
• Capacity: 12 cubic feet
• Refrigeration: Two sections; self-contained; rear mounted
• Defrost: Air defrost; the manual describes an automatic defrost timer that operates four times in 24 hours and resets to the time of the initial first start-up
• Lighting: Automatic lighting
• Temperature control: Digital controller with a microprocessor
• Backing: Galvanized steel
• Door feature: Self-closing and stay-open feature, as stated in the product listing
• Weight: 264 lb
• Manual operating environment: Ambient temperature between +10°C and +40°C, with relative humidity within 55%
• Manual noise information: The manual states that equipment fitted with an integral hermetic condensing unit does not exceed 70 dB under the described conditions and does not generate vibrations affecting its surroundings under normal conditions.

Installation & Requirements

Unpack the unit and remove the white PVC protective film and other transit-protection material. Place the cabinet on a flat surface and adjust its leveling legs so it is level. The manual says to lift the cabinet from the exterior of its base and not to move it by pressing on its surface. If the unit has been positioned horizontally and has an integral condensing unit, wait two hours before activating it.

Choose a location that is not explosive and is not outdoors or exposed to rain. Keep the unit away from direct heat sources, direct sunlight and drafts. The manual calls for free air circulation around the condensing unit, whether integral or remote, and warns that ignoring these conditions can affect cabinet operation. It does not provide a numerical clearance measurement.

Before connecting power, check that the supply conforms to the requirements on the factory label and that it has the stated fail-safe protection or an automatic circuit breaker. The manual does not provide a voltage, amperage, plug type or gas connection specification in the supplied text. Do not cover the equipment label, and replace it immediately if it is damaged. The manual also cautions against removing protection or panels that require tools to remove.

Operation

Connect the power and adjust the thermostat. Allow the unit to reach the desired operating temperature shown on the digital display before placing merchandise inside. Do not put uncovered hot foods or liquids in the cabinet. Package or protect foods when possible, and avoid blocking internal air circulation with unnecessary obstacles.

Limit frequent or prolonged door and drawer openings. After closing a door or drawer, wait a few moments before opening it again. When loading the cabinet, open and fill one drawer at a time to reduce the risk of overbalancing. The manual describes an automatic defrost timer that operates four times in a 24-hour period; its timer resets to the time of the initial first start-up.

Cleaning & Maintenance

Routine cleaning

For hygiene and performance, the manual says to clean the internal basin at least once a week. Switch off the power supply before cleaning. Use an antibacterial detergent on the walls and internal parts. For plastic parts, use a damp cloth, then dry with a soft, clean cloth. Use little or no water, and do not use harsh or abrasive solvents or detergents. Wear protective gloves when cleaning near parts that could cut, including the evaporator and condenser.

Condenser cleaning

The manual recommends cleaning the condenser at least once a month to support performance. Before starting, turn off the equipment and disconnect the plug. Unscrew, rotate and remove the protective grille. Remove dust from the condenser’s front surface with a brush and vacuum cleaner, then restore the grille and the previous equipment conditions.

Periods of inactivity

For an extended period without use, remove products from the cabinet, unplug the unit and clean it as described for periodic cleaning. Cover the cabinet with a cloth that allows air to circulate inside.

Troubleshooting

The cabinet does not operate

Check that the plug is correctly inserted in the socket and that the supply cord is not damaged. If the supply cord is damaged, the manual does not provide a repair procedure in the supplied text.

The required temperature is not reached

Check that the command switch is on and the thermostat range is correctly set. The manual also advises checking whether the cabinet is in a defrost or post-defrost phase, whether the evaporator is covered with frost, and whether dust is blocking the condenser. Confirm that the cabinet is not near a heat source and that air can circulate without interruption around the condensing unit. The supplied manual text lists leak and noise topics in its troubleshooting index but does not provide their remedies.

Applications

The manual describes the equipment family for refrigeration, preparation and sale of salads, fruit, vegetables and cold dishes. The MSF8311’s two refrigerated sections and prep-table format suit ingredient access during sandwich and salad preparation and other food-service work involving chilled items.
