RPW1S

Overview

The Baxter RPW1S is a single-wide retarder/proofer cabinet for bakery operations that need to manage dough through retarding and proofing. Retarding keeps the cabinet cool to slow yeast fermentation, helping prevent dough from rising while it is held or gradually thawed. Proofing uses controlled temperature and humidity to encourage fermentation and dough rise before baking. The manual also describes an automatic Retard/Proof mode, which combines the two stages in one programmed operation.

The RPW1S belongs to Baxter’s modular proofer and retarder/proofer family. The family includes roll-in cabinet configurations, and the manual identifies one-, two- and three-section roll-in models. The cabinets have stainless steel interior and exterior panels. For the RPW1S, Baxter’s product information also identifies a patented airflow system, internally mounted heat and humidity equipment, easy access to that system, no-flush operation, and eye-level digital controls.

Key Features

• Retard and proof functions: Retard dough at a cool temperature to slow fermentation, or use proof mode to provide controlled temperature and humidity for dough rise.
• Automatic Retard/Proof: The manual describes programming a retard period followed by automatic proofing. The cycle can be set for a single day or a seven-day program.
• Digital controls: Controls provide settings for temperature, humidity, timers and operating modes. The LCD control option displays setup choices for proofing, retarding and automatic Retard/Proof operation.
• Patented airflow system: Baxter identifies its airflow system as a product feature.
• Accessible heat and humidity system: Product information identifies an internally mounted system that is easy to access and does not require flushing.
• Stainless steel panels: The manual specifies stainless steel interior and exterior panels that can be cleaned with warm, soapy water.
• Roll-in cabinet format: The product is identified as single wide, and the manual describes the RPW family as including roll-in models.

Specifications

• Manufacturer: Baxter
• Model: RPW1S
• Equipment type: Single Wide Retarder/Proofer
• Functions: Retarding, proofing and automatic Retard/Proof operation
• Cabinet construction: Stainless steel interior and exterior panels
• Airflow: Patented airflow system
• Heat and humidity system: Internally mounted; easy access; no flushing required, according to Baxter product information
• Controls: Digital controls; the manual describes control-panel options, including an LCD option
• Model family format: The manual describes one-, two- and three-section roll-in models in the Proofer and Retarder/Proofer family

Installation & Requirements

The Baxter manual states that proofers and retarder/proofers must be installed by authorized, trained service technicians. The available information does not provide an electrical connection specification for the RPW1S model without a configuration suffix, so confirm the requirements for the specific unit before installation.

Operation

Proofing

Controlled temperature and humidity promote yeast fermentation, which generates gas and causes dough to rise. The manual gives a typical proofing reference of 95°F (35°C) and 85% humidity, noting that settings vary with the product. It says proofing commonly takes 45 to 60 minutes, depending on the product. The LCD control instructions give an adjustable proof temperature range of 65°F to 115°F and humidity range of 25% to 95%. For dry-proofing, the manual instructs operators to set humidity to its lowest setting.

The manual’s product examples are a guide, and it recommends consulting the dough supplier’s technical product reports when establishing settings. Its examples include rolls at 95°F (35°C), 85% humidity and 55 minutes; French crust bread at 90°F (32°C), with 90% humidity for 14-ounce bread and 85% for 10-ounce bread, both for 45 minutes; bagels at 85°F (29°C), 85% humidity and 50 minutes; and croissants at 75°F (24°C), 70% humidity and 30 minutes.

Retarding

Retarding slows yeast fermentation, reduces gas formation and inhibits dough from rising. The manual recommends setting the temperature between 36°F and 38°F (2°C to 3°C) for best results. It says frozen dough takes approximately six hours minimum to thaw at retarder temperatures and notes that the cabinet can provide an environment for storing dough products for up to 48 hours. Dough should not be refrozen after thawing. Condensation may form if product moves directly from the retarder into proofing; the manual recommends allowing it to reach room temperature before placing it in the proofer.

The LCD instructions list a retarder setting range of 34°F to 50°F. The manual notes that an automatic Retard/Proof cycle can bring the cabinet up to proofing temperature without removing the product. In automatic mode, rest and recovery periods are programmed before the proof stage. After a cycle finishes, the unit runs in Proofer mode; to resume the next day’s program, the operator must return to Retarder/Proofer mode and start the cycle again.

Using the controls

The manual describes control-panel options with temperature and humidity displays, timer selection and timer start/stop controls. The LCD control option presents operating choices for proofer, retarder and automatic Retard/Proof mode. In proof mode, the operator selects temperature, humidity and timer settings. In retard mode, the operator selects the temperature and timer. The LCD timer indicates remaining time; when it runs out, the beeper pulses and the timer number flashes. The manual also describes selecting a single-day or seven-day automatic program through the operating parameters.

Cleaning & Maintenance

Before cleaning, the manual’s shutdown instructions say to remove remaining product, turn off the proofer and clean the proofing chamber. For the stainless steel interior, use a clean cloth moistened with warm, soapy water, rinse with clear water and dry with a clean cloth. Clean the outside daily with a clean, damp cloth. Use care around sensitive interior parts, including probes and sensors.

Do not use cleaners containing grit, abrasive materials, bleach, harsh chemicals or chlorine. Do not use steel wool on stainless steel. The manual also says never to spray the cabinet with water or steam or to power wash it. Test new or changed cleaning formulas in an inconspicuous place before using them more broadly.

For maintenance, disconnect electrical power and follow lockout/tagout procedures. The manual calls for authorized service personnel to check the air duct, drain, heater plate, spray nozzle and refrigeration coils, if applicable, every six months. Replace bulbs only with 40-watt incandescent appliance-type bulbs. Contact an authorized service office for repairs or adjustments.

Troubleshooting

• Machine will not turn on: Check that the power cord is plugged in and verify that the main power supply is on. If the unit still will not turn on, contact the local authorized service office.
• Machine will not heat up: Verify that the temperature is set properly. If the problem continues, contact the local authorized service office.

Applications

The RPW1S can support bakery workflows that require dough to be held cool before proofing, frozen dough to be gradually thawed, or prepared dough to rise under controlled temperature and humidity before baking. Its automatic Retard/Proof function is useful when production is planned around a programmed retard period followed by proofing. The manual cautions that dough settings vary by product, so its example chart should be treated as a guide rather than a universal recipe.
