HR7E

Overview

The Hobart HR7E is a single-section electric rotisserie oven. A product listing identifies a capacity of 28–35 chickens. A separate used-equipment listing describes an HR7E with digital controls, four baskets and double pass-through doors. These details describe that listed unit and should not be assumed to establish the configuration of every HR7E.

The available HR7E replacement-parts catalog covers models ML-132092, ML-132093, ML-132094 and ML-132095. Its contents include sections for oven doors, the steel oven back on ML-132094 and ML-132095, oven frame and panels, controls and components, heating and venting, the rotisserie and drive motor, stacking kit, and accessories.

Key Features

• Rotisserie cooking: The HR7E is identified as a commercial electric rotisserie oven.
• Listed capacity: A single-section HR7E listing states a 28–35 chicken capacity.
• Configuration in one listing: A used HR7E listing describes digital controls, four baskets and double pass-through doors. Check the individual unit to confirm its configuration.
• Parts documentation: The replacement-parts catalog includes the membrane keypad assembly, heating components, a blower with fan blade, a quartz lamp, and rotisserie and drive-motor parts. The catalog can help identify components when sourcing parts for a particular machine.

Specifications

• Manufacturer: Hobart.
• Model: HR7E.
• Type: Electric rotisserie oven.
• Section: Single section, as stated in the capacity listing.
• Capacity: 28–35 chickens, as stated for the single-section HR7E.
• Electrical information in one used-equipment listing: 208V, PH1/3, 44.7 amps, 60 Hz; hardwired.
• Standards stated in that used-equipment listing: ANSI, NSF and UL.
• Dimensions in one HR7E listing: 33 1/4 inches deep × 38 7/8 inches wide × 38 3/8 inches high.
• Overall dimensions in another used HR7E listing: 71 inches high × 39 inches wide × 35 inches deep.
• Configuration reported for one used unit: Digital control, four baskets and double pass-through doors.
• Parts-catalog model identifiers: ML-132092, ML-132093, ML-132094 and ML-132095.

The two published dimension sets differ. Confirm the dimensions, electrical details, capacity and included configuration against the specific oven and its identification information before purchase or installation.

Installation & Requirements

One listing for a used HR7E specifies a hardwired electrical connection at 208V, PH1/3, 44.7 amps and 60 Hz. These are listing-specific details, not confirmation of the requirements for every HR7E build. The available source material does not provide installation clearances, ventilation instructions or a full installation procedure. Confirm the requirements for the particular oven before planning its installation.

Applications

The HR7E is listed as a rotisserie oven with a 28–35 chicken capacity for the single-section model. This capacity makes it relevant to commercial foodservice operations preparing rotisserie chicken. A separate listing describes an HR7E with four baskets, but the sources do not specify which foods those baskets accommodate or provide cooking times, temperatures or operating instructions.
